3/4″ Full-Circle Multi-Composite™ Impact Sprinkler

Precision Channel™ Aluminum Arm



  • Full-circle impact – 26° trajectory
  • 3/4″ male NPT base
  • Single (AL30) or dual nozzle (AL30D)
  • Sprinkler Head Does Not Include Nozzle
AL30-C (w/chrome bearing)
(w/plastic spindle)


Aqua-Burst® AL30 Multi-Composite™ Sprinklers are designed to
outlast and outperform all other 3/4” impact sprinkler brands
  • Anodized die-cast aluminum drive arm with Precision Channel Spoon™ for smooth Torque-Driven™ operation and reduced splash-down
  • Composite body is super-strong and impact resistant
  • Highly efficient water distribution at both high and low operating pressures
  • All-brass Seal-Lock bearing creates a debris resistant captive seal for long bearing wear
  • Bearing spindle with debris journal to slow bearing wear
  • Stainless-steel fulcrum pin, arm spring and bearing spring for long wearing reliability
  • Ideal for wheel line, solid set and frost control
  • Works well with either straight bore nozzle or flow-control nozzle with 1/4″ NPT threads
  • Made with domestic and foreign parts
  • Pre-assembled with XC-33 thread sealant
