3/4″ – 1 1/2″ Seal Matic Pivot Control Valves

Assembled in the USA

From domestic and foreign parts

3-Year Diaphragm Guarantee

 SMV75PEG

Features

  • Fully galvanized, ductile iron body and bonnet
  • Brass auto-drain included with PEG model
  • One diaphragm for all working pressures
  • 200 psi max working pressure
  • Highly efficient high-flow, low head loss design
  • Easy in-place maintenance
  • Pressure reducing and pressure sustaining valves come with P-6000 brass pilot

Seal Matic Pivot End Gun Valve

SMV75PEG
SMV1PEG
SMV1.25PEG
SMV1.5PEG
3/4″ w/Auto-Drain and Plug
1” w/Auto-Drain and Plug
1 1/4” w/Auto-Drain and Plug
1 1/2” w/Auto-Drain and Plug

Seal Matic Electric On/Off Valve

SMV75WS
SMV1WS
SMV1.25WS
SMV1.5WS
3/4” w/Solenoid
1″ w/Solenoid
1 1/4” w/Solenoid
1 1/2” w/Solenoid

Seal Matic Electric Pressure Reducing Valve

SMV75EPR
SMV1EPR
SMV1.25EPR
SMV1.5EPR
3/4″ w/P-6000 Pilot/Solenoid
1″ w/P-6000 Pilot/Solenoid
1 1/4” w/P-6000 Pilot/Solenoid
1 1/2” w/P-6000 Pilot/Solenoid

Seal Matic Basic Valve

SMV75B
SMV1B
SMV1.25B
SMV1.5B
3/4” w/Plugs
1” w/Plugs
1 1/4” w/Plugs
1 1/2” w/Plugs

Seal Matic Manual Pressure Reducing Valve

SMV75MPR
SMV1MPR
SMV1.25MPR
SMV1.5MPR
3/4″ w/P-6000 Pilot
1″ w/P-6000 Pilot
1 1/4” w/P-6000 Pilot
1 1/2” w/P-6000 Pilot

Seal Matic Manual Pressure Sustaining Valve

SMV75MPS
SMV1MPS
SMV1.25MPS
SMV1.5MPS
3/4″ w/P-6000 Pilot
1″ w/P-6000 Pilot
1 1/4” w/P-6000 Pilot
1 1/2” w/P-6000 Pilot
